Stratus Extra Wide Extra Tall 47 1/4″ Commercial Grade Open Center Mobile Mid Rise Electric Safety Lock Release Scissor Car Lift SAE-MS9000XT
$4,546.00 USD
2
People watching this product now!
Introducing Stratus SAE-MS9000XT – the perfect choice for any commercial garage. This mid rise scissor lift is specifically engineered with the user in mind. It…
- There is a $250 Surcharge for the following states: OR, WA, ID, MT, ND, SD, and ME
- Is this being shipped to a residential address? An additional $150 will be charged to residential
Description
Introducing Stratus SAE-MS9000XT – the perfect choice for any commercial garage. This mid rise scissor lift is specifically engineered with the user in mind. It’s extra wide and extra tall, standing proudly at 47 1/4″, ensuring you can work on a massive range of vehicles with room to spare. Its 9000 lbs capacity makes lifting heavy vehicles a breeze, and the electric safety lock release guarantees your work is carried out securely. Experience a new approach to car lifting with this top-of-the-line model.
Important Notes
- A $250 Surcharge will be applied to the following: OR, WA, ID, MT, ND, SD and ME
- Sales tax will be automatically waived for out of Texas Buyers
- Lift can ONLY be shipped to Commercial Address, Local Installer or Truck Terminal
- Buyer is responsible for unloading freight – freight companies have a time limit of 30 minutes, any time exceeding will be charged to customer
Product Features
- Extra wide extra tall scissor lift, lifting up to 47 ¼” high
- Open center
- Electric safety lock release
- Pre-wired plug
- Mobile kits make the lift move around easily, included in purchase
- Sensor switch on locks to ensure safety
- Optional 4″ platform extension (sold separately)
- Optional support bar (sold separately)
- Optional set of 4 approach ramp kit for low profile vehicles (sold separately)
- Available in 110V Control Unit (Recommend 30A breaker) or 220V Control Unit (Recommend 20A breaker) / PLC control unit or non-PLC control Unit. The PLC control unit is equipped with an Oil-Immersed motor, Non-PLC Control unit is equipped with a regular motor.
- PLC – Programmable Logic Controller
- Tall car stand includes 9 lock positions, platform raise 4 3/4″ – 5 1/2″ when raising each lock position
- Platform is 24 13/16″ from ground when lift raises to the 1st lock position.
- 8 pcs rubber pads included, 4 of each 1 3/8″ & 2 3/8″
- Dual cylinder structure with anti-surge valves
- Aluminum motor with 24V low voltage control system
- Self-lubricated bushing and bearing
- Proofed by dynamic test with 120% of rated capacity and static test with 150% rated capacity
- Powder coating finish: Granite Gray (RAL 7026) + Rein orange (RAL 2004)
Product Specifications
| Model | MS9000XT |  |
| Capacity | 9,000 LBS | |
| Lifting Time | ~40SEC | |
| Max Height | 47 1/4” (1200 MM) | |
| Min Height | 4 3/4” (120 MM) | |
| Runway Length without Ramps | 62 5/8” (1590 MM) | |
| Runway Length with Ramps | 85 1/4” (2182 MM) | |
| Overall Width | 77 3/16” (1960 MM) | |
| Runway Width | 20 1/2” (520 MM) | |
| Between Runway | 36 1/4” (920 MM) | |
| Motor | 3 HP, 110v / 220V, 60 HZ, 1ph | |
| Oil | AW32 or AW46 | |
| Breaker | 30A | |
| Platform Weight | 1,437 LBS | |
| Platform Dimension | 79” L * 70” W * 10” H | |
| Control Panel Weight | 135 LBS | |
| Control Panel Dimension | 43” L * 18” W * 21” H |
